THE VERTICAL SUBMERGED CANNED MOTOR PUMP RANGE

– Industrial canned motor pumps ISO 15783 or API 685 for submerged applications in tanks –

You are here:

Home
VERTICAL SUBMERGED CANNED MOTOR PUMP…

THE VERTICAL SUBMERGED CANNED MOTOR PUMP RANGE MEETS THE REQUIREMENTS OF CHEMICAL AND PETROLEUM MARKET

Optimex solutions are based on the canned motor technology which presents a monobloc construction. Consequently the shaft line between the motor and the pump is no longer necessary and results a completely sealed pumping unit.

This design reduces the installation and maintenance costs.

CONSTRUCTION:

Mono or Multistage
Standard of construction: ISO 15783 or API685
Compliance with PED directive 2014/68/EU
Ex proof directives (ATEX, CUTR, UL, CSA)

MATERIAL:

Carbon steels
Stainless steel 316L/304L
Duplex Uranus U55
Compliant with the API codes S5, S6, A-8
Others materials possible on demand

FUNCTIONNING AT:

Flow: Up to 700 m3/h
Head: Up to 1000 m

1. Impeller

2. Mobile (Shaft + Rotor)

3. Front & Rear Sleeve Bearing

4. Casing

5. Soleplate

6. Deported Terminal Box

7. Discharge Flange

8. Instrumentation (Temperature probe, pressure switch and other instruments available)
